Stûv 16 cube & H

Categories: , ,

Description

Sober lines

Wood burning stoves that are both sober and pure of line and emphasize the viewing of the flames.
Impressive combustion and high efficiency make the Stûv 16-cube the ideal wood heating solution whether as your main or supplemental heating or simply for pleasure.

Specifications

Combustion technology SBR – Single Burn Rate
Weight of the unit LBS 16/58 : 300 | 16/68 : 324 | 16/78 : 348
Minimum power BTU 15.000
Maximum power BTU 16/58 : 48.000 | 16/68 : 56.000 | 16/78 : 72.000
Wood consumption Kg/hr 16/58 : 1,8 | 16/68 : 2,1 | 16/78 : 2,5
Particle emissions* gr/hr 16/58 : 1,4 | 16/68 : 2,3 | 16/78 : 3,1
Length of logs in vertical position 12″
Length of logs in horizontal position 16/58 : 17″ | 16/68 : 21″ | 16/78 : 25″
Air intake (min.) Ø63 mm | Ø2.5″
Airtight outdoor air intake Option
North american standards UL STD 1482-7 | ULC STD S627-00 | [ 1658-IN & 1668-IN ] EPA 2020 NSPS phase 1 + MONTREAL| [ 1678-IN ] EPA NSPS phase 2
Chimney diameter & type (LINER) Ø6″ (STD) – Ø7″ (OPT) | UL 103 HT | ULC S-629
Chimnet adaptor Ø7″ Option
Dimendion A 16/58 : 22-7/8″ | 16/68 : 26-3/4″ | 16/78 : 30-3/4″
